Zodiac CX40 Robotic Pool Cleaner | Floor, Walls & Waterline | 2-Year Warranty
Transform pool maintenance from a weekly chore into a hands-free routine with the Zodiac CX40 Robotic Pool Cleaner. Engineered for medium-sized in-ground pools up to 10m x 5m, this intelligent cleaner delivers professional-grade results with minimal effort, plug it in, press start, and enjoy crystal-clear water.
2nd Generation Successor to the CX20 and CX35
The CX40 is the second-generation successor to the hugely popular Zodiac CX20 and CX35, the robotic cleaners that thousands of New Zealand pool owners trusted for years. Both Gen 1 models are now discontinued. If you loved your CX20 or CX35, the CX40 is the natural upgrade, same Zodiac reliability, now with smarter mapping, improved filtration, and greater energy efficiency.
Technical Specifications
| Model | Zodiac CX40 (2nd Generation) |
| Succeeds | Zodiac CX20 and CX35 (now discontinued) |
| Pool Size | Up to 10m x 5m (in-ground pools) |
| Pool Surfaces | Concrete, fibreglass, tile, vinyl, pebble |
| Cleaning Coverage | Floor, walls, waterline |
| Cleaning Cycles | Floor Only (1h 15min) | Full Coverage (2h 30min) |
| Filtration | Dual canisters (150 micron and 60 micron) |
| Suction Technology | Cyclonic (maintains constant suction power) |
| Navigation | Zodiac Smart Mapping Algorithm |
| Cable Length | 15m floating swivel cable |
| Weight | 9.5 kg |
| Power Consumption | 180W |
| Warranty | 2 years manufacturer warranty |
Key Features
- Cyclonic Suction Technology. Maintains consistent, powerful suction throughout the entire cleaning cycle without clogging or slowing down.
- Dual Filtration System. 150-micron canister captures large debris, 60-micron canister traps fine particles for crystal-clear water.
- Zodiac Smart Mapping Algorithm. Systematically calculates the most efficient cleaning path, no missed spots.
- Two Cleaning Modes. Floor Only (1h 15min) or Full Coverage including walls and waterline (2h 30min).
- Plug and Play. No plumbing modifications, no connection to pool filtration system required.
- Energy Efficient. Runs on just 180W, independently of your pool pump and filter.
- 15m Floating Swivel Cable. Tangle-free operation.
- 2-Year Warranty. Full manufacturer warranty included.
What's Included
- Zodiac CX40 Robotic Pool Cleaner
- E-Box control unit with power supply
- 15m floating swivel cable
- Dual filtration canisters (150 micron and 60 micron)
- Quick start guide and owner's manual
- 2-year warranty card
How to Use
- Plug E-Box control unit into a power outlet near your pool
- Lower the CX40 into the water, ensuring the cable is untangled
- Select Floor Only or Full Coverage mode and press start
- When finished, lift out and rinse the filter canisters with a hose
Recommended Cleaning Schedule
- Normal conditions. 1-2 times per week with Full Coverage mode.
- High debris periods. 2-3 times per week after storms, heavy leaf fall, or high pool usage.
- Light maintenance. Floor Only mode for quick touch-ups between deep cleans.
- Filter maintenance. Rinse canisters after each use, deep clean monthly with filter cleaner solution.
Recommended Accessories
- Zodiac CX50 Robotic Cleaner - upgrade for larger pools up to 12m, includes storage caddy.
- Filter Cleaner Soak 1L - keep your CX40 filters performing like new.
- 100 Micron Fine Filter Insert - upgrade filtration for finer particle capture.
Frequently Asked Questions
Q: Is the CX40 an upgrade from the CX20 or CX35?
A: Yes, the CX40 is the official 2nd generation successor to both models, which are now discontinued. It brings improved mapping, better filtration, and greater energy efficiency.
Q: Will this work with my pool type?
A: The CX40 is designed for in-ground pools up to 10m x 5m with concrete, fibreglass, tile, vinyl, or pebble surfaces. Not suitable for above-ground pools or pools larger than 10m x 5m.
Q: Do I need to connect it to my pool's filtration system?
A: No, the CX40 is completely independent with its own filtration system and runs on mains power.
Q: Will it climb my pool walls?
A: Yes, in Full Coverage mode the CX40 cleans floors, walls, and up to the waterline.
Q: Does it work in saltwater pools?
A: Yes, fully compatible with both chlorine and saltwater pools.
Q: What's the difference between the CX40 and CX50?
A: The CX40 suits pools up to 10m x 5m. The CX50 is designed for larger pools up to 12m and includes a storage caddy.
Q: How long does the CX40 last?
A: With proper maintenance, Zodiac robotic cleaners typically last 5-8 years. The CX40 comes with a 2-year warranty.
Q: Can I leave it in the pool all the time?
A: We recommend removing it after each cleaning cycle to extend its lifespan.
